- Certificate / Product Information -

RAVENOL WATERCRAFT Mineral 2-Takt

RAVENOL WATERCRAFT Mineral 2-Takt is 2-stroke engine oil based on high quality base oils with an ash less additive package for optimum lubricity and excellent corrosion protection.
RAVENOL WATERCRAFT Mineral 2-Takt is especially designed for use in fresh water-cooled outboard engines with separate (Auto lube systems) or mixed lubrication.
RAVENOL WATERCRAFT Mineral 2-Takt meets the requirements of the National Marine Manufacturers Association NMMA TC-W3 (CE 50S Yamaha, Mercury).

Application Notes


RAVENOL WATERCRAFT Mineral 2-Takt is recommended for “TC-W3” Fluids in all outboard engines according to the prescribed mixing ratio from the engine manufacturer. It can also be used for engines operating in seawater.
Typical mixing ratio: 1: 50
Follow the manufacturers recommendations!

Quality Classifications

RAVENOL WATERCRAFT Mineral 2-Takt is approved to:

Specifications

API TB, ISO-L-EGB, JASO FB

Approvals

NMMA TC-W3, RL-29901H

Characteristic

RAVENOL WATERCRAFT Mineral 2-Takt offers:

· Contains additives, designed on the characteristics of outboard engine

· An excellent corrosion protection in all oil-wetted engine parts

· Immediate, homogeneous mixture with the used fuel (including lead-free)

· An effective pressure and temperature resistant oil film

· An excellent anti-wear performance

· A clean burning with no deposits

· Low coking

· High wear protection

RAVENOL WATERCRAFT Mineral 2-Takt

Article number: 1153210
Packages:

1L|1153210-001-01-999

4L|1153210-004-01-999

10L|1153210-010-01-999

20L|1153210-020-01-999

60L|1153210-060-01-999

208L|1153210-208-01-999

1000L|1153210-001-06-999

Characteristics Unit Data Audit
Colour blau -
Density at 20°C kg/m³ 872 EN ISO 12185
Viscosity at 40°C mm²/s 70,0 DIN 51 562
Viscosity at 100°C mm²/s 9,7 DIN 51 562
Viscosity index VI 118 DIN ISO 2909
Pourpoint °C -24 DIN ISO 3016

All indicated data are approximate values and are subject to the commercial fluctuations.

PDF-Download

All information correspond to the best of our knowledge to the actual situation of the cognitions and our development. Subject to alterations. All references made to DIN-norms are only for the description of the goods. There is no guarantee. In case there will be any problems please contact the technical service.

24.03.2016
