RAVENOL Vakuumpumpenöl ISO VG 32
RAVENOL Vakuumpumpenöl ISO VG 32 is optimum alloyed and high level performance industrial oil with a wide range of applications throughout the industry. It is characterized by good viscosity-temperature behavior, high resistance to aging and reliable corrosion protection.
Effective additives ensure even under extreme loads an excellent wear protection. Neutral behavior to sealing materials.
Application Notes
RAVENOL Vakuumpumpenoel ISO VG 32 is suitable for the lubrication of vacuum pumps (rotary vane pumps, diffusion pumps, turbo pumps), where mineral oils are required, as well as for mist lubrication and crankcase.
RAVENOL Vakuumpumpenoel ISO VG 32 oil can be used very well for the lubrication of crankcases.
Quality Classifications
RAVENOL Vakuumpumpenöl ISO VG 32 is tried and tested for aggregates specifying:
Specifications
DIN 51506 VC, ISO 6743-3 DVA und DVC, Leybold-Heraeus 175, Edwards Ultragrade 19, Alcatel 100, 119 und 120, PVR Rotant, Becker Vakuumpumpen, Hyvac 93055, Ulvac 100, BUSCH VM und VMH, Balzers P3, Kinney Type A, Beckmann 19, Fisherbrand 19, SAVANT SPO-1
Characteristic
RAVENOL Vakuumpumpenöl ISO VG 32 offers:
- High performance level
- Very good viscosity-temperature behavior
- High resistance to aging
- Excellent wear protection
- Reliable corrosion protection
- Neutral to seal materials
![RAVENOL Vakuumpumpenöl ISO VG 32 RAVENOL Vakuumpumpenöl ISO VG 32](../../../../../../../typo3temp/pics/3cccb314ee.jpg)
Article number: 1330704
Packages:
1 L|1330704-001-01-999
5 L|1330704-005-01-999
10 L|1330704-010-01-999
20 L|1330704-020-01-999
60 L|1330704-060-01-999
208 L|1330704-208-01-999
Characteristics | Unit | Data | Audit |
---|---|---|---|
Density at 15°C | kg/m³ | 875 | EN ISO 12185 |
Viscosity at 40°C | mm²/s | 32,7 | DIN 51 562 |
Viscosity at 100°C | mm²/s | 5,4 | DIN 51 562 |
Viscosity index VI | 98 | DIN ISO 2909 | |
Flash point (COC) | °C | 220 | DIN ISO 2592 |
Pourpoint | °C | -24 | DIN ISO 3016 |
FZG-Test A/8,3/90 damage loading step | 12 | DIN 51 354 |
All indicated data are approximate values and are subject to the commercial fluctuations.
All information correspond to the best of our knowledge to the actual situation of the cognitions and our development. Subject to alterations. All references made to DIN-norms are only for the description of the goods. There is no guarantee. In case there will be any problems please contact the technical service.
