- Certificate / Product Information -

RAVENOL Hydraulikoel TS 15 (HLP)

RAVENOL  Hydrauliköl TS 15 (HLP) is optimal alloyed mineral hydraulic oil with a high performance level and a wide application area of the whole industry. It is characterised by good viscosity temperature behaviour, a high aging resistant and a solid corrosion protection.

Efficient additives offer an excellent corrosion protection even under extreme loads. The behaviour of sealing materials is neutral.

Application Notes

RAVENOL Hydrauliköl TS 15 (HLP) is for universally use in all hydraulic systems. It is recommended in high performance hydraulic systems with high pressure pumps of all types, in sensitive control systems, for hydraulic systems in agriculture, to supply small gearboxes and for use in circulating systems.

Quality Classifications

RAVENOL  Hydrauliköl TS 15 (HLP) is tried and tested for aggregates:

Specifications

DIN 51 524, Part 2, Vickers-Pumpentest, FZG-Test A 8,3/90: 12. Laststufe, DENISON HF-1, HF-0, HF-2, MIL-H 24 459, AFNOR NFE 48 603 HM, Cincinnati Milacron P68 (HM-32), P69 (HM-68), P70 (HM-46)

Characteristic

RAVENOL  Hydrauliköl TS 15 (HLP) offers:

  • a high performance level
  • a very good viscosity temperature behaviour
  • a high aging resistant
  • an excellent corrosion protection
  • a solid corrosion protection
  • neutrality of sealing materials

RAVENOL Hydraulikoel TS 15 (HLP)

Article number: 1323102
Packages:

1 L|1323102-001-01-100

5 L|1323102-005-01-000

20 L|1323102-020-01-000

60 L|1323102-060-01-100

208 L|1323102-208-01-000

1000 L|1323102-001-06-000

Characteristics Unit Data Audit
Colour gelbbraun visual
Density at 20°C kg/m³ 868 EN ISO 12185
Viscosity at 40°C mm²/s 15,5 DIN 51 562
Viscosity at 100°C mm²/s 3,5 DIN 51 562
Viscosity index VI 103 DIN ISO 2909
Flash point (COC) °C 196 DIN ISO 2592
Pourpoint °C -32 DIN ISO 3016

All indicated data are approximate values and are subject to the commercial fluctuations.

PDF-Download

All information correspond to the best of our knowledge to the actual situation of the cognitions and our development. Subject to alterations. All references made to DIN-norms are only for the description of the goods. There is no guarantee. In case there will be any problems please contact the technical service.

24.03.2016
