RAVENOL Gearbox Hydraulic Actuator Fluid GHA-F is a special hydraulic fluid based on synthetic and mineral oil with non-ash forming additives. The properties of RAVENOL Gearbox Hydraulic Actuator Fluid GHA-F are decisively determined by its special formulation. We guarantee an excellent low temperature stability.

Application Notes

RAVENOL Gearbox Hydraulic Actuator Fluid GHA-F is designed for a range of application from -40°C to +100°C.

RAVENOL Gearbox Hydraulic Actuator Fluid GHA-F is used in electrically controlled MCP gearboxes from Peugeot/Citroën and in Dualogic and Selespeed gearboxes from FIAT/Alfa Romeo and therefore, shows ideal performance as a special hydraulic fluid in electrohydraulic and electrically controlled gears and gearshifts.

Quality Classifications

RAVENOL Gearbox Hydraulic Actuator Fluid GHA-F is tried and tested for aggregates specifying:

Practice and tested in aggregates with filling

Peugeot/Citroën 9979.A4 for MCP Automated Gearbox FIAT/Alfa Romeo 15081616 CS SPEED for Dualogic and Selespeed Gearbox FIAT 9.55550-SA1 Nr. F005.F98 Hydraulic fluid for Toyota hydraulic gearbox actuation systems, P/N 08886-02206

Characteristic

RAVENOL Gearbox Hydraulic Actuator Fluid GHA-F offers:

• Extremely low pour point.
• Improved viscosity and friction value characteristics.
• Very good wear protection.
• An excellent thermal stability.
• Improved EP properties.
• Good foaming characteristics.
• Neutral behaviour towards sealing compounds.
• Reliable protection against corrosion.
