- Certificate / Product Information -

RAVENOL Hydraulikoel TS 22 (HLP)

RAVENOL  Hydrauliköl TS 22 (HLP) is optimal alloyed mineral hydraulic oil with a high performance level and a wide application area of the whole industry. It is characterised by good viscosity temperature behaviour, a high aging resistant and a solid corrosion protection. Efficient additives offer an excellent corrosion protection even under extreme loads. The behaviour of sealing materials is neutral.



Application Notes

RAVENOL Hydraulikoel TS 22 (HLP) is for universally use in all hydraulic systems. It is recommended in high performance hydraulic systems with high pressure pumps of all types, in sensitive control systems, for hydraulic systems in agriculture, to supply small gearboxes and for use in circulating systems.

Quality Classifications

RAVENOL  Hydrauliköl TS 22 (HLP) is tried and tested for aggregates specifying:

Specifications

DIN 51 524, Part 2, Vickers-Pumpentest, FZG-Test A 8,3/90: 12. Laststufe, DENISON HF-1, HF-0, HF-2, MIL-H 24 459, AFNOR NFE 48 603 HM, Cincinnati Milacron P68 (HM-32), P69 (HM-68), P70 (HM-46)

Characteristic

RAVENOL  Hydrauliköl TS 22 (HLP) offers:

  • a high performance level
  • a very good viscosity temperature behaviour
  • a high aging resistant
  • an excellent corrosion protection
  • a solid corrosion protection
  • neutrality of sealing materials
RAVENOL Hydraulikoel TS 22 (HLP)

Article number: 1323103
Packages:

1 L|1323103-001-01-000

5 L|1323103-005-01-000

10 L|1323103-010-01-100

20 L|1323103-020-01-000

60 L|1323103-060-01-000

208 L|1323103-208-01-000

1000 L|1323103-001-06-000

Characteristics Unit Data Audit
Colour yellow brown visual
Density at 20°C kg/m³ 870 EN ISO 12185
Viscosity at 40°C mm²/s 23,4 DIN 51 562
Viscosity at 100°C mm²/s 4,5 DIN 51 562
Viscosity index VI 98 DIN ISO 2909
Flash point (COC) °C 205 DIN ISO 2592
Pourpoint °C -30 DIN ISO 3016
Aging stability, TOST H 2000 DIN 51 587

All indicated data are approximate values and are subject to the commercial fluctuations.

PDF-Download

All information correspond to the best of our knowledge to the actual situation of the cognitions and our development. Subject to alterations. All references made to DIN-norms are only for the description of the goods. There is no guarantee. In case there will be any problems please contact the technical service.

24.03.2016
