RAVENOL ATF DEXRON III H is universal ATF (Automatic Transmission Fluid) for all automatic transmission with and without controlled torque converter lockup clutch (so-called GKÜB = gear-clutch-lock) which are required for the transmission fluid type Dexron III H.

RAVENOL ATF DEXRON III H is designed on the basis of hydrocracked oils and PAO with special additives and inhibition to ensure the proper operation of the automatic transmission.

Application Notes

RAVENOL ATF DEXRON III H was developed for use in automatic transmissions with electronically controlled converter lockup clutch.

RAVENOL ATF DEXRON III H is especially suitable for use in transmissions with ATF Dexron III H specification.

RAVENOL ATF DEXRON III H is mixable with all ATF brands. It is advised to rinse with RAVENOL ATF DEXRON III H before, beforehand the final filling with RAVENOL ATF DEXRON III H is made.

Quality Classifications

RAVENOL ATF DEXRON III H is tried and tested and proved in aggregates with the following filling instruction:

Specifications

Dexron III H, Allison C4, Allison TES-389

Approvals

MAN 339 Typ Z-2, ZF TE-ML 04D, 14B, 16L, 17C, Voith 55.6336.3x Extended Drain (G1363), Allison TES-389 AA-33072010 (ATF III H)

Practice and tested in aggregates with filling

MB 236.1, 236.6, 236.9, 236.10, ZF TE-ML 05L, VOLVO Transmission Oil 97341, VOLVO 1161521 und 1161621

Characteristic

RAVENOL ATF DEXRON III H offers:

• Very good lubricating properties even at low temperatures in winter
• High and stable viscosity index
• Very low flow point
• Excellent oxidation stability
• Extensive protection against wear, corrosion and foaming
• Well tuned friction properties
• Neutral behavior towards sealing materials
• Neutral behavior by inhibition towards non-ferrous metals
